Included in the Special Offer
Spectra LL1505C Laser Level
Spectra HL450 Receiver
Carry Case
Tripod & Staff
New for 2025, the Spectra Precision LL1505C. This model replaces the Spectra LL300S and now has some new features such as Bluetooth allowing you to control the laser from your phone using Spectra’s laser App, the laser speed can be controlled as well as setting slopes making this a one-man operation.
When in use with the HL760 receiver the LL1505C allows the user to access the grade match feature which allows control of grade between two points over unknown ground eliminating manual slope calculations.
Spectra says the LL1505C is the most rugged laser available with its IP66 rating it is fully waterproof and dustproof. It has also been tested to withstand drops of up to 1m on concrete. Back by Spectra’s 5-year warranty the LL1505C is tough enough for any job site.
The LL1505C’S rotation speed can be adjusted between 300, 600 & 900rpm.
12v car chargers are available to buy for these lasers, and the battery pack can be charged in or out of the laser. Alkaline batteries can also be used.
With a 5/8’’ thread mounted on the bottom and rear of the laser it is suited to both horizontal and vertical applications.
Should your laser be disturbed on site the laser will stop rotating, a flashing red LED will display on the laser to avoid any errors.
Specification
Operating range – 1200m (600m in either direction of the laser)
Accuracy ±1.5mm over 30m
Power – Spectra B10 rechargeable battery pack or 4x Alkaline Dcell batteries.
Battery life – up to 55hours
Rotation Speed – 300, 600, 900RPM
IP Rating – IP66
Warranty – 5years (laser)
Charging time – Approx. 10hours.
Operating temperature - -20 to 50c
Laser Source – class 2
Receiver
The Spectra HL450 features a digital readout which gives you an accurate figure in either mm or inches. This is displayed on 2x LCD screens, one on the front and another on the rear of the HL450, it has 3 tolerance options and a large detection window of 102mm.
The HL450 receiver also has an anti -strobe feature to avoid interference from beacons on site and is covered by Spectra’s 3 year instant swap out warranty.
The Spectra HL450 is compatible with any brand of red beam rotating laser.
HL450 Specification
IP Rating – IP67
Receiver detection range – 102mm
Anti strobe – Yes
Units – mm / cm / inch
Sound – Low, loud & off
Operating time – Up to 70hours
Power – 2x AA battery
Working diameter – 200M
Warranty – 3 years
Precision settings – 3 options - ±0.5mm, 1mm, 5mm
Mounting clamp – Spectra C45
LCD – 2 screens, front & back
Audio – 105DB
Beam colour detected – Red
Auto Shut off – After 30mins
Tripod Specification
GS18 Aluminium medium weight tripod
Flat top mounting head
Carry shoulder strap
Extending legs with quick release clamps
Head Diameter size – 16cm
Thread size – 5/8’’
Closed length – 97cm
Maximum extended length – 165cm
Weight – 3.2kg
Staff Specification
5m, 5 section Aluminium staff
Comes with a carry sleeve / bag
Clip on bubble provided
Weight – 1.6kg
Closed height – 1.10m
Easy to read graduations.
Front readings... ‘’E’’ graduations
Rear readings... MM/CM readings from the bottom up.
Calibration
All our laser levels are calibrated before dispatch and are provided with a calibration certificate valid for 12months. Sealand Survey Centre is a Spectra approved service centre and is certified to carry out repairs on the full range of Spectra products.
