Survey

Topcon

Topcon HiPer XR GNSS Receiver

No. of Channels	448
GPS	Yes
GLONASS	Yes
GALILEO	Yes
BeiDou	Yes
SBAS	Yes
QZSS	Yes
Dimensions (mm)	138.6 x 138.6 x 97.2
Weight w/Battery	995g
External Power Connector	Yes
Operating Time	≤10 Hours
Dust/Water rating	IP67
4G Modem (Celluar)	Yes
UHF Radio Modem	Optional
Tilt Functionality	Yes
Max Tilt Angle	60
Imaging Functionality	No
Camera Sensor	No
Warranty	1 Year
Compatible File Formats	MAXML, TXT, CSV, GC3, TP3, DXF, DWG, SHP, Land XML, DGN, PXY, GEO, PDF, KML

Topcon

Topcon FC-6400 Controller

Trimble

Trimble SPS 930

Range w/Prism	2500m
Accuracy w/Prism	1mm + 1ppm
Time w/Prism	Standard: 1.2 sec, Tracking: 0.4 sec
Range Non-Prism	800m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Standard: 1-5 sec, Tracking: 0.4 sec
Minimum Resolution/Accuracy	1"
Laser Pointer	Yes
Weight	5.25kg
Battery Operation	≤ 6 Hours
IP Rating	IP65
Software OnBoard	No
Warranty	2 Years

Trimble

Trimble S9

Range w/Prism	2500m
Accuracy w/Prism	1mm + 2ppm
Time w/Prism	Standard: 1.2 sec, Tracking: 0.4 sec
Range Non-Prism	1,300m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Standard: 1-5 sec, Tracking: 0.4 sec
Minimum Resolution/Accuracy	0.5", 1"
Laser Pointer	Yes
Weight	5.5kg
Battery Operation	≤ 6.5 Hours
IP Rating	IP65
Software OnBoard	No
Warranty	2 Years

Trimble

Trimble S7

Range w/Prism	2500m
Accuracy w/Prism	1mm + 2ppm
Time w/Prism	Standard: 1.2 sec, Tracking: 0.4 sec
Range Non-Prism	1300m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Standard: 1-5 sec, Tracking: 0.4 sec
Minimum Resolution/Accuracy	1", 2", 3", 5"
Laser Pointer	Yes
Weight	5.5kg
Battery Operation	≤ 6.5 Hours
IP Rating	IP65
Software OnBoard	No
Warranty	2 Years

Leica

Leica TS16 P 5" R500 Robotic

Range w/Prism	3500m
Accuracy w/Prism	1mm + 1.5ppm
Time w/Prism	Prism: 2.4sec, Prism Fast: 1.5sec
Range Non-Prism	1000m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Any surface: 2sec
Minimum Resolution/Accuracy	1", 2", 3", 5"
Laser Pointer	Yes
Display	5" colour, touchscreen
Weight	5.8kg
Battery Operation	≤ 8 Hours
IP Rating	IP55
Software OnBoard	Yes
Warranty	2 Years

Leica

Leica TS13 Mid-Range Robotic Total Station

Range w/Prism	3500m
Accuracy w/Prism	2mm + 2ppm
Time w/Prism	Prism: 2.4sec, Prism Fast: 1.5sec
Range Non-Prism	1000m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Any surface: 2sec
Minimum Resolution/Accuracy	1", 2", 3", 5"
Laser Pointer	Yes
Display	Option
Weight	5kg
Battery Operation	≤ 8 Hours
IP Rating	IP55
Software OnBoard	Option
Warranty	2 Years

Leica

Leica FlexLine TS10 Manual Total Station

Range w/Prism	3500m
Accuracy w/Prism	2mm + 1.5ppm
Time w/Prism	Prism: 2.4sec, Prism Fast: 2sec
Range Non-Prism	500m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Any surface: 2sec
Minimum Resolution/Accuracy	1", 2", 3", 5"
Laser Pointer	Yes
Display	5" colour, touchscreen
Weight	4.9kg
Battery Operation	≤ 13 Hours
IP Rating	IP66
Software OnBoard	Yes
Warranty	2 Years

Leica

Leica FlexLine TS07 5" R500 Manual Total Station

Range w/Prism	3500m
Accuracy w/Prism	2mm + 1.5ppm
Time w/Prism	Prism: 2.4sec, Prism Fast: 2sec
Range Non-Prism	500m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Any surface: 2sec
Minimum Resolution/Accuracy	1", 2", 3", 5", 7"
Laser Pointer	Yes
Display	3.5" colour, touchscreen
Weight	4.5kg
Battery Operation	≤ 16 Hours
IP Rating	IP66
Software OnBoard	Yes
Warranty	2 Years

Leica

Leica FlexLine TS03 Manual Total Station

Range w/Prism	3500m
Accuracy w/Prism	2mm + 1.5ppm
Time w/Prism	Prism: 2.4sec, Prism Fast: 2sec
Range Non-Prism	500m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Any surface: 2sec
Minimum Resolution/Accuracy	2", 3", 5"
Laser Pointer	Yes
Display	3.5" Greyscale
Weight	4.3kg
Battery Operation	≤ 16 Hours
IP Rating	IP66
Software OnBoard	No
Warranty	2 Years

Topcon

Topcon GT-1200 Series Robotic Total Station

Range w/Prism	5000m
Accuracy w/Prism	1mm + 2ppm
Time w/Prism	Fine: 0.9sec, Rapid: 0.6sec, Tracking: 0.4sec
Range Non-Prism	1000m
Accuracy Non-Prism	2mm + 2ppm
Time Non-Prism	Fine: 0.9sec, Rapid: 0.6sec, Tracking: 0.4sec
Minimum Resolution/Accuracy	0.5", 1"
Laser Pointer	Yes
Bluetooth Range	LongLink 600m
Display	4.3" Colour LCD
Weight	5.8kg
Battery Operation	≤ 8 Hours
IP Rating	IP65
Software OnBoard	Yes
Method	Direct Dive Motors
Max Speed	180⁰ per second
Warranty	3 years on instrument, 5 years on motors

Leica

Leica GS18I Imaging GNSS GPS Network Rover / Radio Rover Receiver

No. of Channels	555
GPS	Yes
GLONASS	Optional
GALILEO	Optional
BeiDou	Optional
SBAS	Optional
QZSS	Optional
Dimensions (mm)	173 x 173 x 109
Weight w/Battery	1250g - 3550g
External Power Connector	Yes
Operating Time	≤8 Hours
Humidity	95%
Dust/Water rating	IP66
4G Modem (Celluar)	Optional
UHF Radio Modem	Optional
Tilt Functionality	No
Max Tilt Angle	No
Imaging Functionality	Yes
Camera Sensor	Single 1.2MP
Warranty	1 Year
Compatible File Formats	DXF, LandXML, MxGenio, Terramodel, Carlson, Japan XML, DTM data, XML data, ASCII
